Espressif ESP32-S2 User Manual

Chapter 2. API Reference
• Call the function heap_trace_start() to begin recording all mallocs/frees in the system. Call this
immediately before the piece of code which you suspect is leaking memory.
• Call the function heap_trace_stop() to stop the trace once the suspect piece of code has finished exe-
cuting.
• Call the function heap_trace_dump() to dump the results of the heap trace.
An example:
#include "esp_heap_trace.h"
#define NUM_RECORDS 100
static heap_trace_record_t trace_record[NUM_RECORDS]; // This buffer must be in␣
,→internal RAM
...
void app_main()
{
...
ESP_ERROR_CHECK( heap_trace_init_standalone(trace_record, NUM_RECORDS) );
...
}
void some_function()
{
ESP_ERROR_CHECK( heap_trace_start(HEAP_TRACE_LEAKS) );
do_something_you_suspect_is_leaking();
ESP_ERROR_CHECK( heap_trace_stop() );
heap_trace_dump();
...
}
The output from the heap trace will look something like this:
2 allocations trace (100 entry buffer)
32 bytes (@ 0x3ffaf214) allocated CPU 0 ccount 0x2e9b7384 caller␣
,→0x400d276d:0x400d27c1
0x400d276d: leak_some_memory at /path/to/idf/examples/get-started/blink/main/./
,→blink.c:27
0x400d27c1: blink_task at /path/to/idf/examples/get-started/blink/main/./blink.c:52
8 bytes (@ 0x3ffaf804) allocated CPU 0 ccount 0x2e9b79c0 caller␣
,→0x400d2776:0x400d27c1
0x400d2776: leak_some_memory at /path/to/idf/examples/get-started/blink/main/./
,→blink.c:29
0x400d27c1: blink_task at /path/to/idf/examples/get-started/blink/main/./blink.c:52
40 bytes 'leaked' in trace (2 allocations)
total allocations 2 total frees 0
(Above example output is using IDF Monitor to automatically decode PC addresses to their source files & line number.)
The first line indicates how many allocation entries are in the buffer, compared to its total size.
In HEAP_TRACE_LEAKS mode, for each traced memory allocation which has not already been freed a line is printed
with:
• XX bytes is number of bytes allocated
• @ 0x... is the heap address returned from malloc/calloc.
• CPU x is the CPU (0 or 1) running when the allocation was made.
Espressif Systems 987
Submit Document Feedback
Release v4.4
