The motif is displayed in red when it is incorrectly positioned and therefore not possible. It becomes blue
when its position is correct:
3. Frame representing the recommended engraving area
4. Boxing center
5. Optical center
6. Circle representing the “prohibited” area of the edger
This is the area in which the edger cannot engrave.
7. Circle representing the “prohibited” area of the field of vision
The area is centered on the optical center in FV. The half distances and heights must therefore be
correctly indicated. If this is not the case, their frame is displayed in red.
8. 1/2 Pupillary distance
9. Pupillary height
10. Arrows for moving the motif on the shape
The motif can also be moved with the mouse.
11. Modification of motif dimensions
It is possible also to resize the motif with the mouse. Position the mouse on the white mark to vary the
size:
12. Identical transfer of the selected motif to the other lens
When the button is active (displayed in dark blue), the modifications made to the selected motif are
applied simultaneously to the other motif.
13. Symmetry of the selected motif with the other lens
14. Lens edge tracking
This function only applies to text motifs.
15. Green button = comment to be read
16. Save
You access the job management screen again.
17. Exit without saving
18. Position in X and Y of the engraving position
19. Engraving size
The default size is as big as the largest engraving dimension, equal to 5mm.
