Lower
Mid-lower
Move the cursor along the shape to see the bevel profile in the zoom window.
The edger calculates the shelf bevel value to be applied between each of the four or eight points of
each area.
The bevel trajectory on the rear surface is modified in the work screen. The result can be viewed in
the zoom window.
Press to perform a back chamfer of the assembly aid.
The chamfer is selected .
The result can be viewed in the zoom window.
Press systematically to tilt of the bevel (mounting aid).
The bevel tilt is selected .
The result can be viewed in the zoom window.
>
>
>
>
>
>
4
5
USER MANUAL> II. EDGING A LENS
45
Pro-E 600_Pro-E 700 > v1 -10.18
