ES415.1 - User’s Guide34
Getting Started ETAS
5 Getting Started
This chapter contains information on the following topics:
• "General Installation Recommendations" on page 34
• "Assembly" on page 36
• "Drilling Template" on page 50
• "Applications" on page 51
• "Wiring Examples" on page 53
• "Wiring" on page 58
5.1 General Installation Recommendations
5.1.1 Assembly Environment and Components for Attaching the Module
Adhere to the technical data of the modules for operation, such as
• the vibration resistance of the modules (only assemble modules on sprung
masses, for example, and not on wheel suspensions or directly on the
engine) and
• the temperature resistance of the modules (for example do not assemble
modules on the engine, turbocharger, exhaust manifold or within their
vicinity).
5.1.2 Potential Equalization in the Vehicle and Mounting the Modules
The module can be damaged or destroyed.
The modules of the ES400 line are only admissible for assembly and
operation on components or in locations which guarantee adherence
to the technical data of the modules during operation (see chapter 7
on page 70).
Potential equalization in the vehicle over the shield of the
Ethernet connecting cables of modules may occur!
Mount the modules only to components with the same electrical
potential or insulate the modules from the components.
