ETAS ES415.1 - Measurement Probes and Cables

ES415.1 - User’s Guide98
ETAS
8.4 Measurement Probes and Cables
8.4.1 CBN400.1 Isolating Measurement Probe
Fig. 8-22 CBN400.1 Isolating Measurement Probe
The CBN400.1 Isolating Measurement Probe for use with the ES411.1/ ES415.1
module offers four input channels for voltages up to +/-1000 V DC, a separate
signal conditioning for each channel with voltage reduction and isolation (max.
+/-1000 V DC). The cable meets the safety standard EN 61010-1.
Temperature rated for: -40 to +85°C
8.4.2 CBN401.1 Isolating Measurement Probe
Fig. 8-23 CBN401.1 Isolating Measurement Probe
The CBN401.1 Isolating Measurement Probe for use with the ES411.1/ ES415.1
module offers four input channels for voltages up to +/-10 V DC, a separate
signal conditioning for each channel with voltage reduction and isolation (max.
+/-1000 V DC). The cable meets the safety standard EN 61010-1.
Temperature rated for: -40 to +85°C
Note
For additional information, see the user's guide of the product.
Product Length Order number
CBN400.1-1 1 m F 00K 107 227
Note
For additional information, see the user's guide of the product.
Product Length Order number
CBN401.1-1 1 m F 00K 107 228
