ES415.1 - User’s Guide56
ETAS
5.5.4 ES400 Modules with ES910.3 and Drive Recorder (Rapid Prototyping)
Fig. 5-19 ES400 Modules with ES910.3 and Drive Recorder (Rapid Prototyping)
Cable in
Fig. 5-19
Function Order name
1 Ethernet adapter cable (100 Mbit/s) CBAE330 (con-
nected to cable 2)
2 Ethernet connection cable(1 Gbit/s) CBE230 (con-
nected to cable 1)
3 Power supply and Ethernet cable Daisy Chain
modules
CBEP430,
CBEP4305
ECUECU
Ambient/
Exhaust
Pressure
Lambda
Drive Recorder
Vehicle
10/100 MBit/s
Ethernet
1 GBit/s
Ethernet
1
2
Power Supply
Daisy Chain Modules
3
Daisy Chain Measurement Modules
Voltage Sensor
Voltage
Tempera-
ture
Frequency,
Counter Results,
Times
ES410
ES411
ES413
ES415
ES420
ES421
ES441
