ES415.1 - User’s Guide94
ETAS
8.2.5 CBEX400.1 Cable
Fig. 8-15 CBEX400.1 Cable
Ethernet extension cable to increase the length of ES4xx/ES63x/ES93x Ethernet
cables. Can also be used to connect ES4xx via PC, ES600 or ES1135 alternatively
while keeping cable installation through bulkhead.
Robust, waterproof and dust-proof (IP67).
Temperature rated for: -40 °C to +125 °C / -40 °F to +257 °F
8.2.6 ES4xx_BRIDGE
Fig. 8-16 ES4xx Bridge
Ethernet bridge connecting blocked ES400 modules. Facilitates very compact
measurement setups. IP67 compliant.
Product Length Order number
CBEX400.1-3 3 m F 00K 105 294
Product Order number
ES4xx_BRIDGE F 00K 105 684
