ES415.1 - User’s Guide 45
ETAS Getting Started
Preparing the Component
To drill the openings in the component:
1. Drill two holes in the selected component.
Connecting the Module to the Component
To connect the ES400 module to the component, you need two screws M3 and
a screwdriver.
To connect the module and the component:
1. Position the module to the right of the other com-
ponent.
2. Align the threaded drill holes of the integrated
assembly elements on the right-hand side of the
module to the openings in the component.
3. Insert one screw into a hole in the component.
4. Screw the screw from the right-hand side of the
component into the module.
Both parts are now connected mechanically on one
side.
5. Insert the other screw into the other hole in the
component.
6. Screw the screw from the right-hand side of the
component into the module.
Both parts are now completely connected mechan-
ically.
The pivot of the integrated assembly element can be screwed around 6 mm out
of the module.
Use the drilling template to prepare the component
(see Fig. 5-13 on page 50).
Screw the two parts together without getting them
off-thread!
Screw the two parts together without getting them
off-thread!
