ETAS ES415.1 - Page 80

ES415.1 - User’s Guide80
Technical Data ETAS
Characteristics
Maximum input voltage resolution
(16-bit)
±100 mV measurement range:
3.6 V
±1 V measurement range:
37.2 V
±10 V measurement range:
366 V
±60 V measurement range:
2.16 mV
Maximum measurement error ±100 mV measurement range:
±(100 V + |U
IN
| * 0.1%)
±1 V measurement range:
±(500 V + |U
IN
| * 0.05%)
±10 V measurement range:
±(3 mV + |U
IN
| * 0.05%)
±60 V measurement range:
±(16 mV + |U
IN
| * 0.2%)
Max. voltage drift (temperature),
temperature range -40 °C to +85 °C
±100 mV measurement range:
8 V/K
±1 V measurement range:
8 V/K
±10 V measurement range:
36 V/K
±60 V measurement range:
3.6 mV/K
Max. voltage drift (temperature),
temperature range +85 °C to
+120 °C
±100 mV measurement range:
150 V/K
±1 V measurement range:
150 V/K
±10 V measurement range:
360 V/K
±60 V measurement range:
3.6 mV/K
Input impedance Measurement ranges ±0.1 V, ±1V:
> 10 M || < 300 pF
Measurement ranges ±10 V, ±60 V:
> 2 M || < 400 pF
Module not powered:
> 2 M || < 400 pF
