4. When in ZOOM mode, the mouse cursor will change to a different icon in different areas of the screen.
User can control PTZ direction, zoom, and focus by clicking directly on screen:
Figure 4-4 Zoom Express Control
The screen is divided into a 4x4 grid. The function of each section is defined as below:
• 1: Left and up
• 2, 3: Up
• 4: Right and up
• 5, 9: Left
• 8,12: Right
• 13: Left and down
• 14, 15: Down
• 16: Right and down
• 6, 7, 10, 11: Not used
4.12 SEARCH
By mouse: Right-click to bring up the menu bar and click to enter Search Menu.
By front panel: Press ”Search” key to enter Search Menu directly.
1
2
3
4
5
6
7
8
9
10
11
12
16
15
14
13
