5.3.3 Motion
Figure 5-4 Camera Menu – Motion
Camera: Select the camera you wish to adjust. “Title” will change to the title name of the selected camera.
Enable: Check box to enable motion detection. Other motion options will not be available unless this
feature is selected.
Log: Check box to record motion events in the log.
Main Monitor: Monitor display options when a motion event occurs.
No change: No change on the main monitor display.
Full screen: A full screen of the active camera will display on the main monitor.
Pre-alarm Record: Check box to record several moments before the motion event. (Pre-alarm recording
rate will follow “Normal” frame rate setting)
Buzzer: Check box to enable buzzer when a motion event is triggered.
Email Notify: Check box to send email notification when a motion event is detected.
Network Alarm: Check box to send out a network alarm to client PC when motion occurs. (requires
PowerCon software and setting up Alarm Server in Network Setup menu)
Alarm Output: This will transmit a signal through one of the alarm outputs. It can be set to either “NONE”
(not active) or “1”.
Output Type: Output action when motion is triggered.
Timeout: Alarm output lasts for the set time duration.
