12 04-2017 5325 00
DiffusEr NozzlE
ES-FB models only
1. Remove the diffuser nozzle from the sup-
port bracket.
2. Separate the diffuser nozzle compo-
nents.
3. Check that the seal does not have any
tears or has not lost its elasticity; if nec-
essary, replace it.
3
2
4
Fig. 10
1. Cover
2. Seal
3. Diffuser
4. Diffuser nozzle body
RESIDUE CONTAINERS
The residue containers can easily be re-
moved to make emptying and cleaning
quicker.
For safety reasons, the solid residue con-
tainer can only be removed with the door
open.
liquiDs
The appliance displays the liquid residue
the signal microswitch.
To remove the liquid residue container, pro-
ceed as follows:
1. Grasp the sides of the liquid residue con-
tainer, lift it slightly and pull outwards.
2. Empty the container and wash with a
neutral detergent solution.
3. Reposition the liquid residue container.
If the liquid residue container has
not been inserted properly, the “No
container” message will be displayed.
