WATER SUPPLY
The dispenser must use drinking water and
take into account the regulations in force
where the appliance is installed.
from tHE watEr maiNs
For appliances with mains-supplied water.
The appliance must be connected to a
drinking water network.
The mains water pressure must be be-
tween 0.05 and 0.85 MPa (0.5 - 8.5 bar).
Run the water from the mains until it is clear
and dirt free.
of the water inlet solenoid valve by a pipe
(also available in the kit) suitable to with-
stand the water mains pressure, and of a
type suitable for food (minimum internal
diameter of 6 mm).
Installing a tap on the water system
outside the appliance, in an accessible
position, is recommended.
To connect the machine to the water
and hoses.
Do not reuse any existing material.
Fig. 15
1. ¾” inflow pipe
2. Inlet tube
3. Overflow pipe
ovErflow DEvicE
The water inlet solenoid valve is equipped
stops the water from entering if the solenoid
valve or the water level control mechanism
malfunction.
To restore normal operation, proceed as
follows:
1. Drain the water in the overflow pipe;
2. Shut off the appliance’s external water
mains tap;
3. Loosen the fitting which secures the so-
lenoid valve feed pipe in order to relieve
the residual mains water pressure and
tighten it again;
4. Open the tap and turn on the appliance.
