04-2017 5325 00 3
POSITIONING
The appliance is not suitable for outdoor
installations. It must be installed in a dry
environment, with a temperature between
35.6° F and 89.6° F and cannot be installed
in environments where jets of water are
used for cleaning (e.g. large kitchens, etc.).
The appliance must be positioned next to
a wall and in such a way that the back of it
is at a minimum distance of 4 cm from the
wall in order to allow regular ventilation.
Under no circumstances should the ma-
chine be covered with cloths or similar.
The appliance must be placed on a level
surface.
The maximum incline must not exceed 2
degrees; level it up using the adjustable
feet if necessary.
The appliance satisfy the requirements
NSF only when are used 3.93 inches
feet
Positioning on top of a cabinet
The appliance can be placed on a table or
other suitable support (the recommended
height is 32 inches).
We suggest using, where possible, the
appropriate cabinet, where you can place
the waste container, the water supply tank
and, in the event of very hard water, the
descaler.
TECHNICAL SPECIFICATIONS
DimENsioNs
Height 25.59 inches
Width 16.25 inches
Depth 22.25 inches
Depth with door open 33.75 inches
Weight 90 Lbs
25.59
33.46
22.25
33.75
Fig. 2
ElEctrical coNNEctioN
Frequency 60 Hz
Maximum power* 1150 W
* Please refer to the nameplate.
boilEr
20.29 oz capacity with 1100 W heating ele-
ment.
lEvEl of NoisE
The level of continuous, equivalent, weight-
ed acoustic pressure is less than 70 dB.
watEr supply
Water supply from mains with water pres-
sure between 7.3 psig e 123.3 psig (5 and
8.5 Bar).
The appliance's software has been de-
signed to control the water supply from an
internal tank (optional kit).
