Exakt 312 - Rear and Left Side View

Description of the unit
Edition 10_2010 - 38891EN-900-AB
20
Rear and left side view
Abb. 4 Rear and left side of unit
20 Adjusting lever (outer) to adjust the pulley for cutting band
centring
21 Acknowledge button to restart the unit after interruption
22 Main switch to switch on and off the mains voltage
23 Water connection for cooling and flushing
24 Locking lever (inner) to lock the pulley setting
