Maintenance
Edition 10_2010 - 38891EN-900-AB
54
9.5 Maintenance as required
Replacing a
faulty fuse
Replacing a fuse
Danger – electric shock!
Death or serious injuries may be the consequence.
u Prior to replacing the fuse, set the main switch to OFF and unplug the
mains plug.
u Secure against unintentional placing back in operation by others.
u Only use 8 A/T fuse.
You will need a 3 mm hexagon key
Abb. 41 Replacing a fuse
u Remove table and tray (to make it easier to subsequently fit the seal
between the housing and motor cover).
u Remove the seal
u Unscrew the motor cover (4 screws M5) on the rear using the
hexagon key.
u Replace the faulty 8 A/T fuse(s).
u Re-fit the motor cover.
