Maintenance
Edition 10_2010 - 38891EN-900-AB
53
9.4 Annual maintenance
It is recommended to change the yellow belt at least once a year.
On changing the yellow belt, it is recommended to have a colleague
help with the fitting, as the new yellow belt will be stronger.
Abb. 40 Lifting the yellow belt
Replacing the
yellow belt
Replacing the yellow belt
u Remove the cutting band.
u Hold the pulley.
u Carefully lift the yellow belt using a screwdriver and pull off the
pulley.
u Clean the guide groove of the yellow belt.
u Fit the new yellow belt at the bottom first, pull up over the pulley and
press into the groove on the pulley.
u Fit the cutting band.
Checking the
electrical
system and
safety circuit
Electrical system and safety circuit
Have the check undertaken by a service engineer.
