Exakt 312 - Connection to Water and Power Supply

Installation
Edition 10_2010 - 38891EN-900-AB
31
5.5 Connection to water and power supply
Connecting the EXAKT 312 to the drainage system
The EXAKT 312 diamond pathology saw is supplied with loose water
supply and drain hoses. The following section describes how to connect
the EXAKT 312 to the water supply.
Note If the internal laboratory hygiene regulations, for example for infectious
material, stipulate special post-disinfection for the waste water, the water
drain hose can discharge into a suitable container. Otherwise the water
drain hose is connected directly to the drainage system.
You need a screwdriver and two clips per hose.
u Push clips onto both ends of the water drain hose.
u Push the water drain hose onto the drain nozzle on the EXAKT 312.
u Push over the clip and tighten using a screwdriver.
u Push the other end of the water drain hose onto the drain.
– The drain nozzle on the EXAKT 312 is at a height of 330 mm. To
ensure waste water can flow away, there must be a continuous
gradient to the drain.
u Push over the clip and tighten using a screwdriver.
Connecting the EXAKT 312 to the water supply
u Push clips onto both ends of the water supply hose.
u Push the water supply hose onto the water connection on the EXAKT
312.
u Push over the clip and tighten using a screwdriver.
u Push the other end of the water supply hose onto the water supply.
u Push over the clip and tighten using a screwdriver.
The EXAKT 312 has been connected to the water supply.
