Installation
Edition 10_2010 - 38891EN-900-AB
22
5 Installation
The following subjects are described in this chapter:
• Transport
• Installation location
• Installing the EXAKT 312
• Assembly of the unit
• Connection to water and power supply
5.1 Transport
Danger!
Moving the saw base unit with its weight of 150 kg can cause crushes
and back injuries.
u Always use a sack barrow to transport the saw base unit and get the
help of a colleague.
u Push the sack barrow under the saw base unit and tip back.
u Transport the saw base unit to the installation location using the sack
barrow.
5.2 Installation location
On selecting the location ensure the EXAKT 312 diamond pathology saw
is setup in a laboratory that meets the relevant hygiene and safety
regulations.
Discuss the selection of the location for the EXAKT 312 with the
laboratory safety officer.
For safe operation and cleaning of the EXAKT 312 the following points
must be taken in account on selecting the location:
• Setup the EXAKT 312 on a flat, non-slip surface
• Do not setup in a place with a large number of people passing by
• Select location with sufficient space on all sides for operation and
cleaning
• Ensure there is adequate lighting at the installation location – the
EXAKT 312 does not have its own light source
The installation location must give access to a water connection, drain
and power supply with splash-proof socket.
Note The drain nozzle on the EXAKT 312 is at a height of 330 mm. To ensure
waste water can flow away, there must be a continuous gradient to the
drain.
