Technical data
Edition 10_2010 - 38891EN-900-AB
59
12 Technical data
Dimensions EXAKT 312
Unit dimensions width x height x depth
924 x 1527 x 625 [mm]
Weight 150 kg
Working height Approx. 900 mm
Cut height Max. 210 mm
Cut width Max. 350 mm
Pulley diameter 390 mm
Cutting band speed Approx. 200-1200m/min
Connection voltage/frequency
Special voltage
1x 230 V / 50 Hz
1x 200-208V / 50-60Hz
Drive power 0.75 kW to max. 1.1 kW
Maximum current consumption 6 A
Electrical connection (connector type)
Earthed, international
connector type F or CEE 7/4
Diameter of cooling water connection 7.6 mm
Height of cooling water connection 562 mm
Diameter of drain 28 mm
Height of drain 330 mm
Max. cooling water pressure 2 bar
