Exakt 312 - Disinfecting the Bottom Pulley

Cleaning
Edition 10_2010 - 38891EN-900-AB
44
Abb. 32 Belt, yellow
u Lift the top pulley out of the mounting and disinfect the rear side.
u If necessary, change the yellow belt, see section 9.4 Annual
maintenance.
u Disinfect the guide groove and the yellow belt.
The top pulley has now been disinfected.
Disinfecting the bottom pulley
The yellow belt on the bottom pulley can also be cleaned with the work
table fitted. The cleaning slot passes through all the components of the
work table.
u If necessary, remove the yellow belt, see section 9.4 Annual
maintenance.
u Disinfect the guide groove and yellow belt.
u Fit the yellow belt.
The bottom pulley has now been disinfected.
