45
b. Use a clean oil tank with proper capacity, refer to following table:
1. Models and Volume
2. Specification of oil: MOBIL DTE Light 32
#
3. As following drawing (1), press the saw frame to the bottom○
1
, and adjust the pressure between scale○
3
and○
4
Drawing (1):
4. Releasing process of oil pipe (high pressure) as drawing (2), release the oil pipe around 2 or 3 circles to
exhaust the air inside cylinder so as to ensure normal operation
Drawing (2):
○
1
Release 2~3 circles
○
2
Tighten it
