Test Setup - Test Configurator, Timer, and System
94 FTB-700G/800 Series
Test Configurator Overview
 Packet Sync Test Applications:
 Fibre Channel Test Application:
 Wireless Test Application:
Physical
Interface Port
Test Application
Modify Structure
Tes t B lo c k
Interface Block
Arrows
Modify Structure
Protocol Block
Te st B l o ck
Clock Block
Interface Block
Physical
Interface Port
Test Application
Arrows
Physical
Interface Port
Test Application
Modify Structure
Tes t B lo c k
Interface Block
Clock Block
Arrows
