Test Setup - Test Configurator, Timer, and System
264 FTB-700G/800 Series
Streams - Global
Streams - Global
From the Test menu, tap Setup, Test Configurator, the protocol block, and
the Global tab.
The following parameters are displayed and configurable per stream.
 Check boxes:
The first check box (top-left) allows to sequentially enable stream(s)
within the limit of the link capacity.
The check boxes next to the stream numbers allow to enable each
stream individually within the limit of the link capacity.
 Stream Name
1
indicates the name of each stream. Tap on the Stream
Name button to modify the name of each stream.
 Frame Size
1
indicates the frame size of each stream. Tap on the Frame
Size button to modify the frame size of each stream.
 TX Rate
1
indicates the transmission rate for each stream. Tap on the
TX Rate button to modify the transmission rate (see page 271).
 Framing indicates the framing of each stream. Tap on the Framing
button to modify the Network Layer, Transport Layer and VLAN (see
Modify Frame Structure from the MAC/IP/UDP tab).
 VLAN indicates the ID and Priority of each VLAN level for each stream.
Tap on the VLAN button to modify the VLAN settings (see VLAN from
the MAC/IP/UDP tab).
1. See the Profile tab for more information.
