Port Availability on the Visual Guardian Lite
Port Availability on the Visual Guardian Lite
The following table shows the list of available ports as well as a description
and signals supported for each module.
Connector Labelled Description and Supported signal(s) Module
Bantam 1.5M/2M
PORT #1
DS1/1.5M, E1/2M FTB-810/810G/880
1.5M/2M
PORT #2
DS1/1.5M (IN port) FTB-810/810G/880
BNC 2M-155M
PORT #1
E1/2M, E3/34M, DS3/45M, STS-1e/STM-0e/52M, E4/140M,
STS-3e/STM-1e/155M
FTB-810/810G/880
2M/52M
PORT #2
DS3/45M (IN port) FTB-810/810G/880
EXT CLK External clock synchronization: DS1/1.5M, E1/2M, 2MHz,
1PPS
All
AUX AUX Future use FTB-810/
810G/880
RJ-45 ETHERNET
10/100/1000M
PORT #1 and
PORT #2
Ethernet 10/100/1000 Mbit/s electrical FTB-720G/
720G+/
730G/ 730G+/
860/ 860G/860GL
a
RJ-48C 1.5M/2M
PORT #1
DS1/1.5M, E1/2M FTB-810/810G/880
1.5M/2M
PORT #2
DS1/1.5M (IN port) FTB-810/810G/880
SFP ETHERNET
100/1000M
PORT #1 and
PORT #2
Ethernet 100 Mbit/s, 1000 Mbit/s optical
CPRI 1.2288, 2.4576, 3.072, 4.9152, 6.1440 Gbit/s
b
OBSAI 3.072 Gbit/s
b
Fibre Channel 1X/2X/4X
FTB-720G/ 730G/
860/ 860G/860GL
a
100M-4.25
PORT #1 and
PORT #2
b
Ethernet 100 Mbit/s, 1000 Mbit/s optical
CPRI 1.2, 2.4, 3.1, 4.9, 6.1 Gbit/s
OBSAI 3.1 Gbit/s
Fibre Channel 1X/2X/4X
OC-1/STM-0, OC-3/STM-1, OC-12/STM-4, OC-48/STM-16,
OTU1
FTB-720G
+
/730G
+
/ 870/880
155M-2.5G
(PORT #1)
OC-1/STM-0, OC-3/STM-1, OC-12/STM-4, OC-48/STM-16 FTB-810/810G
