Selecting and Starting a Test
84 FTB-700G/800 Series
Wireless Test Application
Wireless Test Application
To select, configure, and start a Wireless test:
1. From the test menu, tap Setup.
2. From the Test Applications tab, under Wireless, tap the CPRI/OBSAI
BERT test icon.
3. From the Test Configurator tab configure the interface structure and
its parameters.
3a. Tap the Modify Structure button to set the basic structure of the
test such as the interface/rate, connector, etc. (refer to Modify
Structure Button on page 97).
3b. Tap the interface block to configure the interface parameters
(refer to page 149). Ensure that the power level is present in the
status bar before proceeding to the next step (refer to Status Bar
on page 28).
Modify Structure
Te st B l o ck
Interface Block
Physical
Interface Port
Clock Block
To Next Page
