Physical Interfaces and LEDs
18 FTB-700G/800 Series
100M-4.25G (PORT #1/#2)
100M-4.25G (PORT #1/#2)
These ports can be used for the following test applications and rates:
Plug the SFP transceiver into the PORT #1 or PORT #2 slot.
Note: Do not replace a SFP/SFP+ while the test is running to avoid distorting
statistics. First stop the test case, replace the SFP/SFP+ and then restart the
test.
Application Rates
PORT
#1 #2
Transport OC-1/STM-0, OC-3/STM-1, OC-12/STM-4, OC-48/STM-16,
OTU1
X
Intelligent Apps
Ethernet
100Mbit/s, 1000 Mbit/s X X
Packet Sync 100Mbit/s, 1000 Mbit/s X X
Fibre Channel 1X, 2X, 4X X X
Wireless CPRI 1.2, 2.4, 3.1, 4.9, 6.1 Gbit/s;
OBSAI 3.1 Gbit/s.
XX
WARNING
Use only EXFO supported transceivers. Refer to this product’s
technical specifications at www.exfo.com for the list of supported
transceivers. Using non-supported transceivers can affect the
performance and accuracy of the test.
