Physical Interfaces and LEDs
NetBlazer 23
ETHERNET 100/1000M (PORT #1/#2)
ETHERNET 100/1000M (PORT #1/#2)
The ETHERNET 100/1000M PORT #1 can be used for the following test
application and optical rates:
Plug the SFP transceiver into the ETHERNET 100/1000M PORT #1 or PORT
#2 slot.
Note: Do not replace a SFP while the test is running to avoid distorting statistics.
First stop the test case, replace the SFP and then restart the test.
Application Rates
PORT
#1 #2
Ethernet 100Mbit/s, 1000 Mbit/s X X
Packet Sync 100Mbit/s, 1000 Mbit/s X X
Fibre Channel 1X, 2X, 4X X X
Wireless CPRI 1.2288, 2.4576, 3.072, 4.9152, 6.1440 Gbit/s;
OBSAI 3.072 Gbit/s.
XX
WARNING
Use only EXFO supported transceivers. Refer to this product’s
technical specifications at www.exfo.com for the list of supported
transceivers. Using non-supported transceivers can affect the
performance and accuracy of the test.
