Test Setup - Test Configurator, Timer, and System
106 FTB-700G/800 Series
Modify Structure Button
Unframed (Interop) is only available with optical interface up to
10G LAN:
For Seed A and Seed B, only available for 10G LAN, the pattern is
generated by the PCS scrambler from a specific seed. The pattern
is not encoded.
For PRBS31 Unscrambled, only available for 10G LAN, the pattern
is generated at the PCS layer. The pattern is not encoded and not
scrambled.
For PRBS and User Pattern: Pattern generated by the PCS
scrambler. The pattern is encoded.
Unframed is only available with optical interface up to 10G LAN:
Encoded pattern generated by the PCS scrambler.
Unframed with Sync is only available with optical interface up to
10G LAN: Pattern of a length corresponding to the number of bytes
transmitted in 1 second.
