Test Setup - Test Configurator, Timer, and System
NetBlazer 159
Interface (iSAM)
Connector allows the selection of the module’s port.
Auto-Negotiation check box when selected (default), indicates to the
remote port which parameters to use. Only available with
10/100/1000M Electrical and 1GE Optical interfaces. For 1GE
Electrical interface, the Auto-Negotiation check box is automatically
selected and is not configurable.
Note: When the Auto-Negotiation check box is selected, the port Speed can be
set. This settings is not applied immediately to the port, it is used only when
the negotiation process is started and take effect only when the
auto-negotiation succeeds. However current setting is applied immediately
to the port when the Auto-Negotiation check box is cleared.
Speed, available with 10/100/1000M Electrical interface, allows the
selection of the interface rate: 10M, 100M, 1GE, or Auto; Auto is only
available when the Auto-Negotiation check box is selected. The
negotiated speed will be displayed next to the Speed field selection.
Note: Full Duplex is used and there is no Flow Control (pause frames received
are ignored).
Lasers OFF at Start-Up allows to automatically turn off all lasers when
starting the module or when switching from one test application of the
same group (Ethernet or Transport) to another. This check box is
cleared by default.
Interface/Rate Connector
10GE WAN
10GE LAN
Port 1 - SFP+
1GE Optical
100M Optical
Port 1 - SFP
Port 2 - SFP
10/100/1000M Electrical Port 1 - RJ45
Port 2 - RJ45
