Test Setup - Test Configurator, Timer, and System
NetBlazer 229
S-OAM and MPLS-TP OAM
Note: Sending traffic with frame size >1518 in switched network may result in
losing all frames.
 Frame Count is the quantity of frames to be transmitted: 1 to 1000 at
the exception of Frame Loss function which is 2 to 1000 (default
is 10); set to 1 for Loopback function with Multicast address type; not
applicable when the Continuous check box is selected at the
exception of Synthetic Loss function.
 TLV Type defines the TLV Type included in the frame: Data (Default),
Test (Loopback (Y.1731 and G.8113.1) and Test functions), and Test
ID (Frame Delay function); is set to Test for the Test function; set to
Data for Synthetic Loss function; not available for Frame Loss
function.
 Payload, available with Data TLV Type, defines the repeating byte
pattern used to fill the payload of the Data TLV: 0x00 to 0xFF (default is
0xCC).
 Test Pattern, available with Test TLV Type, defines the test pattern used
to fill the Test TLV: PRBS31 (default), NULL.
 Test ID, available with Test ID TLV or Synthetic Loss function, defines
the test ID: 0x00000000 to 0xFFFFFFFF (default is 0x00000001).
Restore Carrier Ethernet OAM Defaults
Reverts the Carrier Ethernet OAM test application to its default factory
settings.
Label 2 4 bytes G.8113.1
Continuous 18 bytes for Data TLV Type
21 bytes for Te s t TLV Type
Requesting MEP ID TLV 56 bytes
Parameter Number of bytes to be added Apply to
