Test Results
422 FTB-700G/800 Series
Summary (Link OAM)
Dying Gasp: Indicates that the OAM link partner has sent an
unrecoverable local failure notification (bit 1 of the Flags field is set
to 1).
Link Fault: Indicates that the OAM link partner has sent a link fault
notification (bit 0 of the Flags field is set to 1).
Loopback
Local indicates the Status of the local loopback (Enabled or
Disabled) and allows to Enable or Disable it.
Remote
1
indicates the Status of the remote loopback (Enabled or
Disabled), the number of Successful remote loopback requests, the
number of Fail remote loopback requests, and allows to Enable or
Disable it.
OAMPDU Frame Count
Indicates the number of transmitted and received OAMPDU frames of
the following types:
Information
Loopback Control
Event Notification (received only)
Total indicates the total number of transmitted and received OAMPDU
frames.
1. Statistics are influenced by both the protocol (Parser Action is set to “01”) and physical loopback. The Fail and
Successful counters will be affected by successive enable/disable loopback requests when sending loopback request
to a remote FTB-700G/800 Series module running Link OAM test since it does not provide physical loopback.
