Graphical User Interface Overview
32 FTB-700G/800 Series
Global Indicator
Global Verdict
Reports the global test verdict status when supported by the test
application and enabled (when applicable).
Global Alarm
Indicates the current and history alarm/error status of the test.
Verdict Description
PASS PASS is displayed with a green background when all result values meet the configured threshold
criteria.
FAIL FAIL is displayed with a red background when any result value does not meet the configured
threshold criteria or when a specific alarm is detected (refer to each test application for additional
information).
“--” “--” is displayed with a gray background when at least one of the following conditions is met:
- Pass/Fail verdict is not enabled
- there is no defined criterion
- the test has not run yet.
Background
color
Alarm/
Error
Text displayed Description
Gray Current -- No test result available.
History
Green Current No Alarm No alarm/error has occurred in the last second.
History No alarm/error has occurred during the test.
Red Current Alarms or the name of the alarm. An alarm/error occurred in the last second.
History
Amber History No current alarm/error but at least one
alarm/error has occurred during the test.
