Test Results
NetBlazer 431
Summary (S-OAM and MPLS-TP OAM)
Continuity Check (Peer MEP)
Status displays the status of the continuity check with the peer MEP.
TX CCM indicates the count of transmitted CCM frames.
RX CCM indicates the count of valid CCM frames received. A valid
frame for S-OAM has its source MAC address matching the Peer MEP
MAC address; destination MAC address matching either the unit port
Unicast MAC address or a Multicast class 1 address (refer to 638); and
VLANs matching the unit port VLANs. A valid frame for MPLS-TP OAM
has its destination MAC address matching either the unit MAC address,
FF:FF:FF:FF:FF:FF, or 01:00:5E:90:00:00; VLANs matching the unit port
VLANs; and MPL Labels matching the local MPLS Label Stack
configuration.
Status Description
Loss Continuity Loss of Continuity alarm is active.
Mismerge Mismerge alarm is active.
Unexpected MEG Level Unexpected MEG Level alarm is active.
Unexpected MEP Unexpected MEP alarm is active.
Unexpected Period Unexpected Period alarm is active.
Unexpected MD Level Unexpected MD Level alarm is active.
Receiving CCMs CCM frames from the peer MEP are received without alarms.
