Table 50: Compatibility of Expansion Modules (continued)
Module Type Name No. of Ports Type of Ports Compatible Switch
Series
Clock TM-CLK Clock
Module
NA Reference frequency for
SyncE and 1588v2 precision
time features
X460-G2
VIM5-2Y 2 25GbE
SFP28
optical ports
X465
VIM5-4X 4 10GbE SFP+
optical ports
X465
VIM5-4XE 4 10GbE SFP+
LRM MACsec
capable
optical ports
X465
VIM5-4Y 4 25GbE
SFP28
optical ports
X465
VIM5-4YE 4 25GbE
SFP28 LRM
MACsec
capable
optical ports
X465
V400 Virtual Port Extender
Bridge port extenders (BPEs) are devices that do not fully process packets, nor make forwarding or
filtering decisions. Instead, they simply receive packets from extended ports and forward packets
toward the upstream controlling bridge (an ExtremeXOS-based switch) for L2/L3 processing. This
scheme, based on the IEEE 802.1BR specification, is known as extended edge switching.
The V400 Virtual Port Extender oers the following features:
•
24 or 48 10/100/1000 Base-T ports that provide 10 Gbps copper connectivity.
•
Two or four 1000/10G Base-X SFP+ ports that provide 10 Gbps high-density fiber connectivity.
•
Serial console port.
•
Front panel USB port.
•
PoE+ power on some models.
•
Fixed internal power-supply and fan modules.
All models include either two or four SFP+ ports on the faceplate of each base unit, which can be
provisioned either as uplink or cascade ports. This gives administrators the option to create redundant
links or downstream cascade ports to other V400 units. The SFP+ ports are the only ones that can be
used as uplink ports in a cascading configuration.
The V400 Virtual Port Extender requires that ExtremeXOS (EXOS) version 22.5 (or later) be installed on
the switch to which it is attached. For more information about configuring EXOS for use with this
equipment, see the ExtremeXOS 22.6 User Guide.
Expansion Modules
ExtremeSwitching and Summit Switches: Hardware Installation Guide 114
