Page #392 background image
Table 303: VX-RPS-1000 Environmental Specifications
Operating temperature 0°C to 45°C (32°F to 113°F)
Storage temperature -40°C to 70°C (-40°F to 158°F)
Operating relative humidity 5% to 90% non-condensing
Table 304: VX-RPS-1000 Connector Pin Functions
Pin Function Pin Function
1 12 V power 9 Power good of RPS
2 12 V power 10 Power supply present
3 12 V power 11 12 V current sharing
4 Ground 12 Ground
5 Ground 13 Spare pin
6 Spare pin 14 -55 V current sharing
7 -55 V power 15 -55 V power return
8 -55 V power 16 -55 V power return
3-Slot Modular Shelves: Technical Specifications
Model STK-RPS-1005CH3-E
The following table lists the specifications for the 3-slot modular shelf (model STK-RPS-1005CH3-E).
The shelf is designed for use with the following equipment:
STK-RPS-1005PS Redundant Power Supply on page 102 (model STK-RPS-1005PS)
RPS-150XT Redundant Power Supply on page 98 (model 10932)
Half-Duplex to Full-Duplex Converter (models 10958 and 10959)
Table 305: Physical Specifications
Length 48.20 cm (18.99 in.)
Depth 35.16 cm (13.85 in.)
Height 5.00 cm (1.97 in.)
Weight 2.39 kg (5.27 lb)
Model VX-RPS-CH3
The following table lists the specifications for the 3-slot modular shelf (model VX-RPS-CH3). The shelf is
designed for use with the following equipment:
VX-RPS-1000 Redundant Power Supply on page 103 (model 18202)
Technical
Specifications
ExtremeSwitching and Summit Switches: Hardware Installation Guide 392
