Extreme Networks ExtremeSwitching X440-G2 Series User Manual

11 Replacing Fan Modules
Pre-Installation Requirements
Airflow Direction Requirements
Replacing a Fan Module
For switches with replaceable fan modules, refer to the following information to replace the fan
modules.
Illustrations in this chapter show switches that might not be identical to the ones you are using.
However, the procedure for replacing a fan module is the same for all ExtremeSwitching switches.
Note
Read all of the information in this chapter thoroughly before attempting to replace a fan
module.
Pre-Installation Requirements
You need a 1/4-inch flat-blade screwdriver to replace a fan module.
Caution
Be sure to finish the replacement procedure promptly. The switch could overheat if left
without cooling for an extended period.
Airflow Direction Requirements
•
The air flows from front to back. In these switch models, the fan modules are labeled Air Out.
•
The air flows from back to front. In these switch models, the fan modules are labeled Air In.
X465 switches are available with front-to-back airflow. In this switch, the fan modules are labled Air Out.
All installed fan modules must blow air in the same direction and must match the airflow direction of
the installed power supplies.
Replacing a Fan Module
To replace the fan module in a switch, do the following:
ExtremeSwitching and Summit Switches: Hardware Installation Guide 306

Extreme Networks ExtremeSwitching X440-G2 Series Specifications

General

Form Factor	Rack-mountable
VLAN Support	Yes
Humidity	5% to 95% non-condensing
Model	X440-G2 Series
Port Type	Gigabit Ethernet
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
Stacking	Yes, up to 8 switches
Layer Support	Layer 2/3
Operating Temperature	0°C to 50°C
Product Type	Switch
Jumbo Frames	9216 bytes
AC Power Supply	100-240 VAC, 50-60 Hz
Storage Temperature	-40°C to 70°C
Port Configuration	24 or 48 ports
Power over Ethernet (PoE)	Optional
