Extreme Networks ExtremeSwitching X440-G2 Series User Manual

Table 276: Power Specifications
Voltage input range 100-127/200-240 47 to 63Hz
Nominal input ratings 12.5 A max at 115VAC and 6A max at 230VAC at Full 770 W load
Maximum inrush current 45A at Max 264 VAC at 25C with cold start
Output 54 V, 13.2 A max, 770 W
Power supply input socket and cord IEC/EN 60320-1/C16 AC input receptacles
Power cord wall plug Refer to Power Cord Requirements for AC-Powered Switches and AC
Power Supplies on page 393.
Eciency Minimum eciency: 88% at maximum power output.
Table 277: Environmental Specifications
Operating temperature -10°C to 50°C (normal operation)
Storage temperature -40°C to 70°C
Operating humidity 93% relative humidity, non-condensing at 30C
Operational shock 30 m/s
2
(3 G)
EPS-C2 Redundant Power Supply Technical Specifications
The following tables list the specifications for the EPS-C2 redundant power supply unit (model 10936).
Table 278: Physical Specifications
Dimensions 4.4 cm H x 44.1 cm W x 38.4 cm D
1.73 in H x 17.4 in W x 15.1 in D
Weight (unit only) 1.03 kg (2.27 lb)
Table 279: Other Specifications
Allowable PSU Summit 750W PoE AC PSU
Power cord input plug/socket IEC 320 C13/C14
Power cord gauge Min 18AWG
RPS-90 Redundant Power Supply Technical Specifications
The following tables list the specifications for the RPS-90 redundant power supply unit (model
RPS-90).
Technical
Specifications
ExtremeSwitching and Summit Switches: Hardware Installation Guide 383

Extreme Networks ExtremeSwitching X440-G2 Series Specifications

General

Form Factor	Rack-mountable
VLAN Support	Yes
Humidity	5% to 95% non-condensing
Model	X440-G2 Series
Port Type	Gigabit Ethernet
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
Stacking	Yes, up to 8 switches
Layer Support	Layer 2/3
Operating Temperature	0°C to 50°C
Product Type	Switch
Jumbo Frames	9216 bytes
AC Power Supply	100-240 VAC, 50-60 Hz
Storage Temperature	-40°C to 70°C
Port Configuration	24 or 48 ports
Power over Ethernet (PoE)	Optional
