DC Power Requirements
This system should be installed in a DC-I battery return configuration.
In a DC-I configuration, the battery return conductor should be connected directly to the central oce
power return bus, and not to the equipment frame or the grounding means of the equipment.
Following Applicable Industry Standards
Always follow applicable industry standards.
For more information, see the following ANSI/TIA/EIA standards:
ANSI/TIA/EIA-568-A—the six subsystems of a structured cabling system
ANSI/TIA/EIA-569-A—design considerations
ANSI/TIA/EIA-606—cabling system administration
ANSI/TIA/EIA-607—commercial building grounding and bonding requirements
You can access these standards at: www.ansi.org or www.tiaonline.org.
Site Preparation
ExtremeSwitching and Summit Switches: Hardware Installation Guide 135

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Extreme Networks ExtremeSwitching X440-G2 Series and is the answer not in the manual?

Extreme Networks ExtremeSwitching X440-G2 Series Specifications

General IconGeneral
Form FactorRack-mountable
VLAN SupportYes
Humidity5% to 95% non-condensing
ModelX440-G2 Series
Port TypeGigabit Ethernet
Switching Capacity176 Gbps
Forwarding Rate131 Mpps
StackingYes, up to 8 switches
Layer SupportLayer 2/3
Operating Temperature0°C to 50°C
Product TypeSwitch
Jumbo Frames9216 bytes
AC Power Supply100-240 VAC, 50-60 Hz
Storage Temperature-40°C to 70°C
Port Configuration24 or 48 ports
Power over Ethernet (PoE)Optional
