Extreme Networks ExtremeSwitching X440-G2 Series User Manual

Table 5: Additional Port LED Meanings for PoE Switches: X440-G2-12p-10GE4, X440-
G2-24p-10GE4, and X440-G2-48p-10GE4
Label or Type Color/State Meaning
All front panel ports Steady green Link is OK; port is not powered
Steady amber Link is OK; port is powered; no trac
Blinking green Link is OK and transmitting packets; port is not
powered
Blinking amber Link is OK and transmitting packets; port is
powered
Slow blinking amber No link, or disabled port; port is powered
Alternating amber and green Port has a power fault
O Port is not powered, has no link, or is disabled
Table 6: ExtremeSwitching X440-G2 2-digit Stack Number Indicator
Label or Type Color/State Meaning
Left digit (1) Reserved for future use
Right digit (1 – 8) Indicates the position of this switch in the ExtremeSwitching stack configuration
Upper half blinking This switch is the stack master node
Lower half blinking This switch is the stack backup node
Lit steadily This switch is a standby node in the stack
ExtremeSwitching X450-G2 Series Switches
The X450-G2 series switches provide 24 or 48 Ethernet ports that deliver high-density fast Ethernet or
Gigabit Ethernet connectivity using fixed 10/100/1000BASE-T ports. In addition, some models oer
either 24 or 48 PoE+ ports. The X450-G2 series switches also provide four ports of SFP+ 10 Gb Ethernet
or four ports of SFP 1 Gb Ethernet on the front panel. Each model includes two dedicated stacking ports
on the rear panel.
All X450-G2 ports are full-duplex. They do not support half-duplex operation.
The X450-G2 series switches include the following base models:
•
ExtremeSwitching X450-G2-24t-GE4 Switch Ports and Slots on page 31
•
ExtremeSwitching X450-G2-24t-10GE4 Switch Ports and Slots on page 32
•
ExtremeSwitching X450-G2-48t-GE4 Switch Ports and Slots on page 33
•
ExtremeSwitching X450-G2-48t-10GE4 Switch Ports and Slots on page 34
•
ExtremeSwitching X450-G2-24p-GE4 Switch Ports and Slots on page 35
•
ExtremeSwitching X450-G2-24p-10GE4 Switch Ports and Slots on page 36
•
ExtremeSwitching X450-G2-48p-GE4 Switch Ports and Slots on page 37
•
ExtremeSwitching X450-G2-48p-10GE4 Switch Ports and Slots on page 38
ExtremeSwitching Switches
ExtremeSwitching and Summit Switches: Hardware Installation Guide 30

Extreme Networks ExtremeSwitching X440-G2 Series Specifications

General

Form Factor	Rack-mountable
VLAN Support	Yes
Humidity	5% to 95% non-condensing
Model	X440-G2 Series
Port Type	Gigabit Ethernet
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
Stacking	Yes, up to 8 switches
Layer Support	Layer 2/3
Operating Temperature	0°C to 50°C
Product Type	Switch
Jumbo Frames	9216 bytes
AC Power Supply	100-240 VAC, 50-60 Hz
Storage Temperature	-40°C to 70°C
Port Configuration	24 or 48 ports
Power over Ethernet (PoE)	Optional
