8 Connect the power cord to the power supply and to a grounded AC power outlet.
Warning
Always be sure that the source outlet is properly grounded before plugging the AC power
cord into the AC power supply.
9 If the power supply is equipped with a power cord retainer, use the retainer to secure the power cord
to the power supply.
Replacing a Summit 1100 W AC Power Supply
The Summit 1100 W AC power supplies are compatible with the X450-G2 and X460-G2 PoE switches.
Part number 10941 is compatible with ExtremeSwitching X465 PoE switch models.
These switches have two bays for hot-swappable power supplies. In a switch with a redundant power
configuration, you can replace one Summit AC power supply without powering down the switch.
You need the following tools and materials to replace a Summit 1100 W AC power supply:
Thermal protective gloves
AC power cord, if you will not be re-using the cord from the removed power supply
To replace a Summit 1100 W AC power supply, follow these steps:
1 Disconnect the AC power cord from the wall outlet and from the power supply.
2 Note the orientation of the installed power supply, and the location of the latching tab at the right of
the unit.
Replacing AC Power Supplies
ExtremeSwitching and Summit Switches: Hardware Installation Guide 274
