ports or two 10Gb ports and two stack ports. In the latter configuration, an additional license would
be required for the 10Gb non-stacking ports.
•
Ethernet management port (10/100/1000BASE-T).
•
Serial console port implemented as an RJ45 connector used to connect a terminal and perform local
management.
•
One front panel USB 2.0 port, operational on switches running ExtremeXOS version 22.2 or later.
•
One rear redundant power supply connector.
Figure 5: ExtremeSwitching X440-G2-24t-10GE4 Front Panel
1 = Stack number indicator 4 = 10/100/1000BASE-T copper ports
2 = Console port/Ethernet management port 5 = 1000BASE-X SFP combination ports
3 = USB port (active with ExtremeXOS version 22.2 or later)
Figure 6: ExtremeSwitching X440-G2-24t-10GE4 Rear Panel
1 = Grounding lug
3 = Redundant power input
2 = SFP Ports upgradeable to 10GBASE-X 4 = AC power input socket
ExtremeSwitching X440-G2-24x-10GE4 Switch Ports and Slots
The ExtremeSwitching X440-G2-24x-10GE4 switch ports and slots include:
•
24 front panel 1GBASE-X SFP ports.
•
Four unpopulated front panel 10/100/1000BASE-T (RJ45) ports.
•
Four unpopulated rear panel 1GBASE-X SFP+ ports that can be used as either 1Gb ports or 10Gb
ports, where the 10Gb configuration requires an upgrade through additional licensing..
ExtremeSwitching Switches
ExtremeSwitching and Summit Switches: Hardware Installation Guide 18

Extreme Networks ExtremeSwitching X440-G2 Series Specifications

General

Form Factor	Rack-mountable
VLAN Support	Yes
Humidity	5% to 95% non-condensing
Model	X440-G2 Series
Port Type	Gigabit Ethernet
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
Stacking	Yes, up to 8 switches
Layer Support	Layer 2/3
Operating Temperature	0°C to 50°C
Product Type	Switch
Jumbo Frames	9216 bytes
AC Power Supply	100-240 VAC, 50-60 Hz
Storage Temperature	-40°C to 70°C
Port Configuration	24 or 48 ports
Power over Ethernet (PoE)	Optional
