b Insert and tighten the retaining screws you removed in step 3. The clock module uses Phillips
screws and the VIM and SSD modules use slotted screws.
Figure 246: Tighten Screws on the Inserted VIM5 Module
Figure 247: Tighten Screws on the Inserted SSD Module
Figure 248: Tighten Screws on the Inserted Clock Module
1= retaining screw locations
Removing and Replacing Expansion Modules
ExtremeSwitching and Summit Switches: Hardware Installation Guide 310
