Extreme Networks ExtremeSwitching X440-G2 Series User Manual

Table 215: Physical Dimensions
Summit X770-32q switch Height: 1.73 inches (4.4 cm)
Width: 17.6 inches (44.8 cm)
Depth: 20.4 inches (51.9 cm) including the PSU and installed fan modules.
Table 216: Weight
Summit X770-32q switch 18.0 lb (8.2 kg)
Summit X770 fan module 0.36 lb (0.16 kg)
550 W AC PSU 2.75 lb (1.2 kg)
550 W DC PSU 2.50 lb (1.1 kg)
Table 217: Packaged Dimensions
Summit X770-32q switch Height: 6.5 inches (16.5 cm)
Width: 23.4 inches (59.3 cm)
Depth: 26.2 inches (66.5 cm)
Table 218: Packaged Weight
Summit X770-32q switch 23.2 lb (10.5 kg)
Summit X770 fan module 0.50 lb (0.20 kg)
Table 219: Fan Speed
Minimum speed 4500 RPM
Maximum speed 18000 RPM
Power: Summit X770-32q
Table 220: Summit X770-32q: Power for Each of the Two Installed AC Power Supplies
Nominal input ratings 100 to 240 V , 50/60 Hz, 2.5 A
Input current 2.25 A @ 100 V (low-line)
0.9 A @ 240 V (high-line)
Heat dissipation 225 W, 768 BTU/hr
Power consumption 225 W, 768 BTU/hr
16
Switch weights include installed fan module. They do not include power supplies.
Technical Specifications
ExtremeSwitching and Summit Switches: Hardware Installation Guide 364

Extreme Networks ExtremeSwitching X440-G2 Series Specifications

General

Form Factor	Rack-mountable
VLAN Support	Yes
Humidity	5% to 95% non-condensing
Model	X440-G2 Series
Port Type	Gigabit Ethernet
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
Stacking	Yes, up to 8 switches
Layer Support	Layer 2/3
Operating Temperature	0°C to 50°C
Product Type	Switch
Jumbo Frames	9216 bytes
AC Power Supply	100-240 VAC, 50-60 Hz
Storage Temperature	-40°C to 70°C
Port Configuration	24 or 48 ports
Power over Ethernet (PoE)	Optional
