Table 15: X590 Front Panel System LEDs
Label or Type Color/State Meaning
MGMT (Management) Steady green Normal operation
Power-on self test (POST) passed
Blinking green POST or diagnostics in progress
Blinking amber Any of the following:
•
POST failed
•
System overheated
•
Power supply failed
•
Fan unit failed
O No power
ACT Blinking green Management port packet transmitting or receiving
O No packet transmitting or receiving
LK (Link) Steady green Management port link up
O No link up or port disabled
P1, P2
(Power Supply)
Steady green Power on
Blinking amber Any of the following:
•
Power supply failure
•
Over voltage
•
Over current
•
Over temperature
O Power o; no power attached
F1 - F4 (Fan) Steady green Normal operation; all diagnostics pass
Blinking amber Fan module failure
O No power to fan module
Table 16: X590 Front Panel Port LEDs
Location Speed Color/State Meaning
Ports 1-24 10Gb/1Gb Steady green Link OK
Blinking green Port transmitting or receiving
O No link, or port disabled
Ports 25-28 40Gb
(no partition)
Steady blue Link OK
Blinking blue Port transmitting or receiving
O No link, or port disabled
10Gb
(partitioned)
Steady green Link OK
Blinking green Port transmitting or receiving
O No link, or port disabled
ExtremeSwitching Switches
ExtremeSwitching and Summit Switches: Hardware Installation Guide 62

Extreme Networks ExtremeSwitching X440-G2 Series Specifications

General

Form Factor	Rack-mountable
VLAN Support	Yes
Humidity	5% to 95% non-condensing
Model	X440-G2 Series
Port Type	Gigabit Ethernet
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
Stacking	Yes, up to 8 switches
Layer Support	Layer 2/3
Operating Temperature	0°C to 50°C
Product Type	Switch
Jumbo Frames	9216 bytes
AC Power Supply	100-240 VAC, 50-60 Hz
Storage Temperature	-40°C to 70°C
Port Configuration	24 or 48 ports
Power over Ethernet (PoE)	Optional
