Room Scheduling System • Room Agent Installation and Configuration 33
3
Sensor Output Type radio button (see figure 27 on the previous page) — Select one
of these radio buttons to denote how the occupancy sensor is wired to the TLS 520M,
TLS 725M, or TLS 1025M scheduling panel or TLP Pro 520M touchpanel:
• Control
• Relay - NC (Normally Closed)
• Relay - NO (Normally Open)
