HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
1-3
HDP5000 Process Flow (in table format)
Reviewing the HDP5000 Boot-up Sequence
Step Process
1 The Card feed stepper turns ON (to check for a card in the card path).
2 The Lam Headlift turns until the head up position is returned from the Headlift
Sensor).
3 The Film transfer take-up Motor turns ON to take up any slack in the film.
4 The Print Headlift turns until head up position is returned from Headlift
Sensor.
5 The Print Ribbon moves forward until it finds the yellow panel, pauses,
advances to magenta, then backs up to yellow (the Ribbon Sensor detects
the color of the ribbon).
6 The Transfer Film advances forward two panels from supply (advances until
the Print Film Sensor senses 2 marks on the Film).
7 The Transfer Film advances forward one panel from supply (advances until
the Print Film Sensor senses 1 mark on the Film).
8 The Transfer Film reverses for one panel onto supply (reverses until the Print
Film Sensor senses 1 mark on the Film).
9 The Transfer Film reverses for one panel onto supply (reverses until the Print
Film Sensor senses 1 mark on the Film).

Fargo HDP5000 Specifications

General

Maximum resolution	300 x 300 DPI
Print speed (color)	7 card/h
Print speed (monochrome)	14 card/h
Product color	Black
Internal memory	16 MB
Total input capacity	100 sheets
Compatible operating systems	Windows 2000 / XP / Server 2003 / Vista (32 bit) Mac OS X v10.4 / v10.5 Linux

Weight and Dimensions

Weight	7300 g
Dimensions (WxDxH)	313 x 235 x 292 mm
