Fargo HDP5000 User Manual

RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
10-8
Cleaning the Magnetic Encoder
Step Procedure
1 Open the front cover and remove the Film Cartridge.
2 Remove the Magnetic Cover to access the Magnetic Head.
3 Remove the Magnetic Head. See Display A below.
3 Use an alcohol wipe from the cleaning kit to clean the Magnetic Head. See
Display B below.
4 Replace the Magnetic Head and Magnetic Cover.
Display A
Display B

Fargo HDP5000 Specifications

General

Maximum resolution	300 x 300 DPI
Print speed (color)	7 card/h
Print speed (monochrome)	14 card/h
Product color	Black
Internal memory	16 MB
Total input capacity	100 sheets
Compatible operating systems	Windows 2000 / XP / Server 2003 / Vista (32 bit) Mac OS X v10.4 / v10.5 Linux

Weight and Dimensions

Weight	7300 g
Dimensions (WxDxH)	313 x 235 x 292 mm
