Reviewing the Lamination Module Sequence of Operations
The LAM sequence of operations begins after printing has occurred with the Card Printer.
Step Process
1 The card is fed onto the Lamination Module.
2 The card is fed to the Card Position Sensor.
3 The Lamination Take-up Motor begins cycling until the Lamination Sensor
detects the mark.
4 The Card Feed Motor activates to place the leading edge of the card on the Lam
Roller.
5 The Lam Roller Lift Motor cycles until the Transfer Roller Lift Sensor detects the
roller is down.
6 The Card Feed Motor and the Lamination Drive Motor activate for the length of
the card.
7 The Lam Roller Lift Motor cycles until the Lam Roller Lift Sensor detects the
roller is up.
