RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP5000 High Definition Card Printer/Encoder User Guide (Rev. 1.3)
2-23
Printer Components: Card Input and Output Hoppers
Type Description
Card Cartridge The Card Cartridge will hold a maximum of 100 cards (based on a
standard 30 mil card thickness).
Printer Components: Card Output Hopper and Reject Hopper
Type Description
Card Output
Hopper
HDP5000/HDP5000-LC:
All standard HDP Card Printers provide a 200 card capacity Card
Output Hopper (based on a standard 30 mil card thickness). (Note:
This Hopper stores the cards after they are printed.) Shown in the
lower left.
Reject hopper functionality when connected to the Flipper Module.
The storage is available on the output tray or the Lamination
Module.
Reject Hopper Shown in the upper left of the image below.
